Program Control Paper Cutting Machine/Paper Cutter/Guillotine Machine
WT auto microcomputer program control cutting machine,intelligent automatical unloading paper machine and lifter.The machine can automatically complete the load and unload,clean up,transit,palletizing for various types of paper.with high productivity,low labor intensity,short auxiliary work time,reduce production costs,can provide the design and manufacture for cutting line with a variety of specifications and different combinations.
| Quantity: | |
|---|---|
-
WT-PC1150
-
WT
-
8441100000
QZYK1150D-8M10 Auto Double Hydraulic Program Control Paper Cutting Machine
Main Technical Data:
| Model Parameters | 660 | 780 | 920 | 1150 | 1300 | 1370 | 1640 | 2000 | 2200 | ||
| M | M | M | M | A | M | M | A | M | M | M | |
| Cutting Width (mm) | 660 | 780 | 920 | 1150 | 1300 | 1300 | 1370 | 1640 | 1640 | 2000 | 2200 |
| Cutting Length (mm) | 660 | 780 | 920 | 1150 | 1300 | 1300 | 1370 | 1600 | 1600 | 1600 | 1600 |
| Cutting Height (mm) | 110 | 110 | 110 | 160 | 120 | 120 | 160 | 120 | 160 | 170 | 170 |
| Workbench Protraction Length (mm) | 510 | 510 | 610 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Workbench Height (mm) | 930 | 930 | 930 | 930 | 930 | 930 | 930 | 930 | 930 | 930 | 930 |
| Motor Power (kW) | 3 | 3 | 3 | 5.5 | 5.5 | 5.5 | 5.5 | 7.5 | 7.5 | 7.5 | 7.5 |
| Maximum Paper Pressing Pressure (dan) | 3000 | 3000 | 3500 | 3500 | 5000 | 5000 | 5500 | 5500 | 5500 | 6500 | 6500 |
| Cutting Speed (times/min) | 42 | 42 | 42 | 42 | 36 | 42 | 42 | 36 | 42 | 42 | 42 |
| Net Weight (kg) | 1900 | 2100 | 2300 | 3800 | 3300 | 3500 | 4500 | 55000 | 6500 | 9000 | 10000 |
| Boundary Dimension (m) | 1.5*1.8*1.5 | 1.6*1.9*1.5 | 2.3*2.3*1.5 | 2.5*2.7*1.6 | 2.7*2.6*1.6 | 2.8*3.2*1.7 | 3*3*1.6 | 3.7*3*1.7 | 3.9*3*1.7 | ||
| Package Size (m) | 1.8*2.1*1.7 | 1.9*2.2*1.7 | 2.4*1.4*1.7 | 2.6*1.7*1.9 | 2.8*1.4*1.9 | 2.8*1.7*2.0 | 3.1*1.7*2 | 3.8*1.7*2.5 | 3.8*1.7*2.5 | ||
Installation Dimension:
| 660 | 780 | 920 | 1150 | 1300 | 1370 | 1640 | 2000 | 2200 | |||
| M | M | M | M | A | M | M | A | M | M | M | |
| L | 1.5 | 1.6 | 2.3 | 2.5 | 2.7 | 2.7 | 2.8 | 3 | 3 | 3.0 | 3.0 |
| W | 1.8 | 1.9 | 2.3 | 2.7 | 2.6 | 2.9 | 3.2 | 3 | 3.2 | 3.7 | 3.9 |
| H | 1.5 | 1.5 | 1.5 | 1.6 | 1.6 | 1.6 | 1.7 | 1.6 | 1.7 | 1.7 | 1.7 |
QZYK1150D-8M10 Auto Double Hydraulic Program Control Paper Cutting Machine
Main Technical Data:
| Model Parameters | 660 | 780 | 920 | 1150 | 1300 | 1370 | 1640 | 2000 | 2200 | ||
| M | M | M | M | A | M | M | A | M | M | M | |
| Cutting Width (mm) | 660 | 780 | 920 | 1150 | 1300 | 1300 | 1370 | 1640 | 1640 | 2000 | 2200 |
| Cutting Length (mm) | 660 | 780 | 920 | 1150 | 1300 | 1300 | 1370 | 1600 | 1600 | 1600 | 1600 |
| Cutting Height (mm) | 110 | 110 | 110 | 160 | 120 | 120 | 160 | 120 | 160 | 170 | 170 |
| Workbench Protraction Length (mm) | 510 | 510 | 610 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Workbench Height (mm) | 930 | 930 | 930 | 930 | 930 | 930 | 930 | 930 | 930 | 930 | 930 |
| Motor Power (kW) | 3 | 3 | 3 | 5.5 | 5.5 | 5.5 | 5.5 | 7.5 | 7.5 | 7.5 | 7.5 |
| Maximum Paper Pressing Pressure (dan) | 3000 | 3000 | 3500 | 3500 | 5000 | 5000 | 5500 | 5500 | 5500 | 6500 | 6500 |
| Cutting Speed (times/min) | 42 | 42 | 42 | 42 | 36 | 42 | 42 | 36 | 42 | 42 | 42 |
| Net Weight (kg) | 1900 | 2100 | 2300 | 3800 | 3300 | 3500 | 4500 | 55000 | 6500 | 9000 | 10000 |
| Boundary Dimension (m) | 1.5*1.8*1.5 | 1.6*1.9*1.5 | 2.3*2.3*1.5 | 2.5*2.7*1.6 | 2.7*2.6*1.6 | 2.8*3.2*1.7 | 3*3*1.6 | 3.7*3*1.7 | 3.9*3*1.7 | ||
| Package Size (m) | 1.8*2.1*1.7 | 1.9*2.2*1.7 | 2.4*1.4*1.7 | 2.6*1.7*1.9 | 2.8*1.4*1.9 | 2.8*1.7*2.0 | 3.1*1.7*2 | 3.8*1.7*2.5 | 3.8*1.7*2.5 | ||
Installation Dimension:
| 660 | 780 | 920 | 1150 | 1300 | 1370 | 1640 | 2000 | 2200 | |||
| M | M | M | M | A | M | M | A | M | M | M | |
| L | 1.5 | 1.6 | 2.3 | 2.5 | 2.7 | 2.7 | 2.8 | 3 | 3 | 3.0 | 3.0 |
| W | 1.8 | 1.9 | 2.3 | 2.7 | 2.6 | 2.9 | 3.2 | 3 | 3.2 | 3.7 | 3.9 |
| H | 1.5 | 1.5 | 1.5 | 1.6 | 1.6 | 1.6 | 1.7 | 1.6 | 1.7 | 1.7 | 1.7 |
