QZYK1150D-8M10 Auto Double Hydraulic Program Control Paper Cutting Machine
Main Technical Data:
| Model Parameters | 660 | 780 | 920 | 1150 | 1300 | 1370 | 1640 | 2000 | 2200 | ||
| M | M | M | M | A | M | M | A | M | M | M | |
| Cutting Width (mm) | 660 | 780 | 920 | 1150 | 1300 | 1300 | 1370 | 1640 | 1640 | 2000 | 2200 |
| Cutting Length (mm) | 660 | 780 | 920 | 1150 | 1300 | 1300 | 1370 | 1600 | 1600 | 1600 | 1600 |
| Cutting Height (mm) | 110 | 110 | 110 | 160 | 120 | 120 | 160 | 120 | 160 | 170 | 170 |
| Workbench Protraction Length (mm) | 510 | 510 | 610 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Workbench Height (mm) | 930 | 930 | 930 | 930 | 930 | 930 | 930 | 930 | 930 | 930 | 930 |
| Motor Power (kW) | 3 | 3 | 3 | 5.5 | 5.5 | 5.5 | 5.5 | 7.5 | 7.5 | 7.5 | 7.5 |
| Maximum Paper Pressing Pressure (dan) | 3000 | 3000 | 3500 | 3500 | 5000 | 5000 | 5500 | 5500 | 5500 | 6500 | 6500 |
| Cutting Speed (times/min) | 42 | 42 | 42 | 42 | 36 | 42 | 42 | 36 | 42 | 42 | 42 |
| Net Weight (kg) | 1900 | 2100 | 2300 | 3800 | 3300 | 3500 | 4500 | 55000 | 6500 | 9000 | 10000 |
| Boundary Dimension (m) | 1.5*1.8*1.5 | 1.6*1.9*1.5 | 2.3*2.3*1.5 | 2.5*2.7*1.6 | 2.7*2.6*1.6 | 2.8*3.2*1.7 | 3*3*1.6 | 3.7*3*1.7 | 3.9*3*1.7 | ||
| Package Size (m) | 1.8*2.1*1.7 | 1.9*2.2*1.7 | 2.4*1.4*1.7 | 2.6*1.7*1.9 | 2.8*1.4*1.9 | 2.8*1.7*2.0 | 3.1*1.7*2 | 3.8*1.7*2.5 | 3.8*1.7*2.5 | ||
Installation Dimension:
| 660 | 780 | 920 | 1150 | 1300 | 1370 | 1640 | 2000 | 2200 | |||
| M | M | M | M | A | M | M | A | M | M | M | |
| L | 1.5 | 1.6 | 2.3 | 2.5 | 2.7 | 2.7 | 2.8 | 3 | 3 | 3.0 | 3.0 |
| W | 1.8 | 1.9 | 2.3 | 2.7 | 2.6 | 2.9 | 3.2 | 3 | 3.2 | 3.7 | 3.9 |
| H | 1.5 | 1.5 | 1.5 | 1.6 | 1.6 | 1.6 | 1.7 | 1.6 | 1.7 | 1.7 | 1.7 |
