Phone:
+86 13712624566
Quantity: | |
---|---|
WT10-A
Cnc Bending Machine
500kg
Steel Blade
Engineers Available to Service Overseas
White and Blue
Bending Bridging Cutting Lipping Broaching
0.45/0.53/0.71/1.05/1.42mm
0.03mm
Dxf Dwg Ai Coredraw Plt
Steel Rule Die Making
1.8 Kw 220V/110V 50/60Hz
Worthy Tall
Compound Wooden Cases with Exporting Standard
2700*1150*1540
Dongguan City China Prc
8462219000
Technical Parameters | Blade thickness(mm) | ||||
0.45-0.71 | |||||
Blade height(mm) | 8-32 | ||||
Maximum bending angle | 110 | ||||
Minimum bending radius of 90 degrees(mm) | 0.15 | ||||
Minimum bending size of the front(mm) | 1.5 | ||||
Minimum bending size of the Rear(mm) | 0.5 | ||||
Feeding Accuracy | 0.03/300mm Panasonic Server Motor And High Precision Screw guide | ||||
Bending Flatness | 0.2/100mm | ||||
Bridge Mode | Automatic continuous bridge, bridge height adjustable(15--18mm) Gear Motor drive | ||||
Cutting Mode | Automatic cut-off or swing(Automatic identification alarm and self Monitor)Gear Motor drive Full Power add olecranon pneumatic machine | ||||
Broaching | Double Broaching 'V'shape,Automatic control Broaching depth. Sharp Corners more standard,Small arc finer | ||||
Best Files format | DXF,DWG,AI,CDR,PLT | ||||
Weight | 620kg | volume | 2805*1025*1470 | ||
Total power | 2kw 110V 220V/ 60HZ 50HZ |
